Lab Design

ACX1100 use a home network vlan13 as wan (i-net access), vlan13 is connected to GNS3 virtual machine for futrue use.

• Logical Router Core (LRC): Is the only logical system directly connected to ACX1100, will be used as core router, all other logical system will use it as a central "hop" to the rest of the "world".
• Logical Router 1 (LR1): Stand alone logical system
• Logical Router 2 (LR2): Stand alone logical system
• Logical Router 3 (LR3): Stand alone logical system with additional port used for connection to external arm64 sbc wtih FRR

Each "node" have additional loopback address with /32 network

ACX1100 will provide internet/home network access via source NAT to all logical systems and networks behind them with nat pool (172.20.13.200-172.20.13.205)

Logical systems connection diagram

ACX1100	local ip address	remote ports	remote ip address
ge-0/0/0	172.20.13.1/24 (vlan13)	WAN (home network vlan13)	172.20.13.254/24 (vlan13 - default gateway)
ge-0/1/0	10.0.0.1/30	LRC (ge-/0/1/1)	10.0.0.2/30
lo.0	100.0.1.1/32
Logical Router Core (LRC)	local ip address	remote ports	remote ip address
ge-0/1/1	10.0.0.2/30	ACX1100 (ge-0/1/0)	10.0.0.1/30
ge-0/0/5	10.0.1.2/30	LR1 (ge-0/0/1)	10.0.1.1/30
ge-0/0/6	10.0.2.2/30	LR2 (ge-0/0/2)	10.0.2.1/30
ge-0/0/7	10.0.3.2/30	LR3 (ge-0/0/3)	10.0.3.1/30
lo.123	100.1.2.3/32
Logical Router 1 (LR1)	local ip address	remote ports	remote ip address
ge-0/0/1	10.0.1.1/30	LRC (ge-0/0/5)	10.0.1.2/30
lo.1	100.1.1.1/32
Logical Router 2 (LR2)	local ip address	remote ports	remote ip address
ge-0/0/2	10.0.2.1/30	LRC (ge-0/0/6)	10.0.2.2/30
lo.2	100.2.2.2/32
Logical Router 3 (LR3)	local ip address	remote ports	remote ip address
ge-0/0/3	10.0.3.1/30	LRC (ge-0/0/7)	10.0.3.2/30
ge-0/0/4	10.0.4.1/30 (dhcp-server)	FRR arm64 (eth0)	10.0.4.2/30 (dhcp-client)
lo.3	100.3.3.3/32
FRR (arm64)	local ip address	remote ports	remote ip address
eth0	10.0.4.2/30 (dhcp-client)	ge-0/0/4	10.0.4.1/30 (dhcp-server)
lo0:10	200.4.4.4/32

Physical cabling for logical systems
